Easy Operated High Speed Mixer For Pvc Compounding Vertical / Horizontal Type

China Easy Operated High Speed Mixer For Pvc Compounding Vertical / Horizontal Type supplier
Easy Operated High Speed Mixer For Pvc Compounding Vertical / Horizontal Type supplier Easy Operated High Speed Mixer For Pvc Compounding Vertical / Horizontal Type supplier Easy Operated High Speed Mixer For Pvc Compounding Vertical / Horizontal Type supplier Easy Operated High Speed Mixer For Pvc Compounding Vertical / Horizontal Type supplier

Large Image :  Easy Operated High Speed Mixer For Pvc Compounding Vertical / Horizontal Type

Product Details:

Place of Origin: ZHANGJIAGANG
Brand Name: LB
Certification: CE, ISO
Model Number: LB-1000/3000

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: USD, EUR
Packaging Details: STANDARD PACKAGE
Delivery Time: 60 WORKING DAYS
Payment Terms: L/C, T/T
Supply Ability: 10 SETS PER MONTH
Contact Now
Detailed Product Description
VESSEL VOLUME: 1000L/3000L COOLER MIXER TYPE: VERTICAL HORIZONTAL
NOTOR POWER: 83/110/30KW DISCHARGING: PNEUMATIC
TEMPERATURE: AOTOMATIC MIXTURE MATERIAL: PVC & ADDITIVES

PVC WINDOW & DOOR PROFILE MIXERS COMBINATION WITH VERTICAL/HORIZONTAL TYPE HEATER / COOLER MIXERS



COMPONENTS AND FEATURES:



PVC window & door profiles mixers with combination of horizontal type heater - cooler mixers are an essential and integral part of high performance processing units.

Ideal appliance for fast preparation of mixers in general and PVC compounds in particular, mixer models available in configuration depending of the capacity and materials designing for each specific production requirement.

  • Universal usable
  • Available with different drive options
  • High throughput rates with optimal mixing quality
  • Low operation costs
  • Compact design



USAGE AREAS OF MIXER:



  • PVC Window & Door profiles
  • PVC water pipes
  • PVC cables
  • PVC cable channels
  • PVC Curtain Rails
  • PVC Hoses
  • PVC Water Isolation Membranes
  • PVC Panels
  • PVC Shoe Soles
  • PVC Floor Covers
  • PVC Shrink Film
  • PVC Tent



Optional Accessories:



  • The production will be with soft starter if frequency inverter is not ordered with the machine.
  • The production will be with Microcontroller if PLC is not ordered with the machine.



Mixture quantity:



  • Including all of additives and raw material density, which will be mixed, are calculated as 0.5kg/lt and mixture temperature 120 degrees centigrade. Depend of the auxiliary raw material, the loading system can be different.
  • Changeable quantity is the event of the plant temperature conditions.



Specification for Horizontal Type Heater –Cooler Combination PVC Mixer:





Model

Mixing Container Volume (lt)

(Heater /Cooler)

Motor Power (kw)

(Heater/Cooler)

Discharging
LB-300/600 300/600 40/55/11AC Pneumatic
LB-500/1000 500/1000 55/75/15 AC Pneumatic
LB-500/1600 500/1600 55/75/15 AC Pneumatic
LB-800/2000 800/2000 83/110/22 AC Pneumatic
LB-800/2500 800/2500 83/110/22 AC Pneumatic
LB-1000/3000 1000/3000 83/110/30 AC Pneumatic



ADVANTAGES:



• Maximum capacity and efficiency
• Savings from time
• Save handwork
• Additives used in each product provides the same rate and ensures the continuity of product quality.
• Reduce waste

Easy Operated High Speed Mixer For Pvc Compounding Vertical / Horizontal Type



Easy Operated High Speed Mixer For Pvc Compounding Vertical / Horizontal Type

Easy Operated High Speed Mixer For Pvc Compounding Vertical / Horizontal Type
