Product Details:
|
| Application: | Drain Pipe | Screw Design: | Single-screw |
|---|---|---|---|
| Certification: | CE,ISO | Voltage: | 380V 50HZ 3Phase(Customized),Customer Demand |
| Automatic Grade: | Full-automatic | After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Online Support,Video Technical Support,Field Installation,commissioning And Training |
| Warranty: | 1 Year | Color: | Customised |
| Control: | PLC+Touch Screen | ||
| High Light: | hdpe pipe production line,pe pipe production line |
||
Product:
We Offer pe/pp tube production machine line with CE and ISO9001:2000 Certificate
20-630mm plastic pipe Extrusion line for you
Product name: PE/PP tube production machine line
Feature:
The production line is mainly used by pipe producing line which adopts also PP-R resin as raw material, besides, it is suitable for pipe production adopting PP, PPB, PPC, PE, ABS resins as raw materials.
1. Man-machine option interface and high automation level
2. It adopts a special screw stem to make good plastic-fiction result
3. It adopts compound screw type head to clear memory function effectively;
4. Vacuum forming, constant temperature control to remove stress of pipe material;
5. It adopts common extruding head, adding marking color line for pipe material.
Technology Parameter:
| Unit Model | SJPG-65 | SJPG-90 | SJPG-120 |
| Main motor power(kw) | 30-37 | 55-75 | 90 |
| Cylinder heating power(kw) | 23 | 34 | 48 |
| Length-diameter ratio | 30:1 | 30:1 | 30:1 |
| Production capacity(Kg/h) | 80-100 | 120-150 | 200-220 |
| Vacuum pump power(kw) | 5.5 | 7.5 | 7.5 |
| Water pump power(kw) | 4 | 4 | 4 |
| Mobile motor power(kw) | 0.75 | 0.75 | 1.1 |
| Drawing motor power(kw) | 3 | 4 | 5.5 |
| Cutting motor power(kw) | 2.2 | 2.2 | 3 |
| Power(kw) | 72 | 110 | 160 |
| Equipment arrangement length(mm) | 30 | 36 |
42 |
Specification:
| MODEL | PIPE DIAMETER (MM) | EXTRUDER MODEL | MOTOR POWER |
| LB-63 | 20-63 | SJ65/33 | 55AC |
| LB-110 | 20-110 | SJ65/33 | 55AC |
| LB-160 | 75-160 | SJ75/33 | 90AC |
| LB-250 | 90-250 | SJ75/33 | 110DC |
| LB-315 | 110-315 | SJ90/33 | 160DC |
| LB-450 | 160-450 | SJ90/33 | 160DC |
| LB-630 | 315-630 | SJ120/33 | 280DC |
| LB-800 | 500-800 | SJ150/33 | 315DC |
| LB-1200 | 710-1200 | SJ150/34 | 400DC |
Equipment:
All Extrusion pipe lines can be equipped with various auxiliary equipment in order to meet our customer’s requests and provide solution from a single source.
| Volumetric and gravimetric dosing units |
| Raw material loading units |
| Belling machines |
| Corrugators |
| Ink jet marking units |
| Winding units |
| Tilting tables |
Our Services:
Pre-sales service:
Sales service:
After-sales service:
Our Advantages:
1.LangBo is a high-tech enterprise specializing in the production of plastic processing complete sets of equipment and various plastic pipe moulds, integrating scientific research, development, manufacturing, sales and service.
2. The company integrates the rich design and manufacturing experience accumulated by the sophisticated technical team over the years, with advanced production equipment technology, strict quality assurance measures, scientific management methods, fast and efficient service, and constantly blaze new trails to meet the needs of customers. Products sell well all over the country and exported to many overseas countries and regions won the trust of all parties, the product is in the same industry-leading position in the country.
