Complete production line for PVC/UPVC pipe ranging from 16mm to 800mm diameter. Ideal for manufacturing pipes with various diameters and wall thicknesses for electrical conduit, agricultural, and construction plumbing applications.
Applications
UPVC pipes produced by this line are used for electrical conduit, water supply, sewage systems, house decoration, chemical transportation, and gas distribution lines. Widely utilized in industrial and daily life applications due to their high strength, structural integrity, excellent chemical resistance, durability, thermal stability, non-toxic safety features, and cost-effectiveness.
Production Process
PVC powder + additive → mixing material feeder → twin screw extruder → mould and calibrator → vacuum and cooling tank → spraying cooling machine → haul-off machine → cutting machine → discharge rack or pipe belling machine.
Technical Specifications
| Model/Data |
Pipe Diameter |
Extruder Model |
Speed |
Max Capacity |
| LB-63 |
16-63mm |
LB-51/105 |
1-10m/min |
120kg/h |
| LB-160 |
75-200mm |
LB-65/132 |
1.5-5m/min |
260kg/h |
| LB-400 |
200-400mm |
LB-80/156 |
0.5-1.5m/min |
400kg/h |
| LB-630 |
400-630mm |
LB-92/188 |
0.1-0.8m/min |
650kg/h |
Key Components
Mixer
Features specific design that reduces raw material self-friction, improving energy utilization efficiency. Operates with low noise and dust-free vacuum suction loading.
Twin Screw Extruder Machine
Crafted with top brand components to ensure production stability, efficiency, and machine durability. Conical twin screw extruder design ensures homogeneous mixture, better plastification, and superior conveying efficiency.
Vacuum Calibration & Cooling System
Two-chamber structure with vacuum calibration and cooling parts. Constructed from stainless 304 steel for both vacuum tank and spraying cooling tank. Excellent vacuum system ensures precise pipe sizing.
Haul-off Unit
Three crawler tracks ensure stable and steady pipe running. Haul-off units can be tailored to specific production requirements through general control adjustments.
Cutting Unit
High-accuracy encoder ensures precise and stable cutting length. PLC control system allows for manual operation cutting based on specific application requirements.
Tipping Rack
Automatically tilts to stack pipes neatly, reducing manual handling and ensuring safe, efficient product collection during continuous production operations.
Service & Support
- One year guarantee for entire machine
- 24 hours technical support
- Overseas installation & commissioning services by our engineers
- Post-warranty maintenance guidance and competitively priced spare parts
- Comprehensive operator training services
Delivery & Payment Terms
Delivery: 30 days after order confirmation
Warranty: 12 months
Payment: T/T 30% in advance, T/T 70% before delivery
Packing: Standard export wooden case
