Plastic Water Supply PE HDPE PP PPR Pipe Tube Single Screw Extruder Production/Extrusion Line/Making Machine

1 SET
MOQ
USD EUR
Price
Plastic Water Supply PE HDPE PP PPR Pipe Tube Single Screw Extruder Production/Extrusion Line/Making Machine
Features Gallery Product Description Ratings & Review Request A Quote
Features
Specifications
After-sales Service: Engineers Availiable To Service
Screw Number: One
Condition: New
Automatic Grade: Fully Automatic
Application: Corrugated Pipe
Model Number: SJ65/33
Highlight:

pipe expander machine

,

pvc pipe socketing machine
Basic Infomation
Place of Origin: ZHANGJIAGANG
Brand Name: LB
Certification: CE ISO
Model Number: LB
Payment & Shipping Terms
Packaging Details: NORMAL PACKAGE
Delivery Time: 45 WORKING DAYS
Payment Terms: L/C,T/T
Supply Ability: 15 SETS PER MONTH
Product Description
Complete extrusion line for manufacturing high-quality plastic pipes with temperature resistance, corrosion resistance, abrasion resistance, and high strength properties.
Applications
Ideal for electric threading pipes, auto threading pipes, protective sleeves, machine tools, packaging and food machinery, electric locomotives, engineering installation, lighting fixtures, automation instrumentation, and various industrial applications.
System Configuration
  • Feeding machine
  • Conical Single-screw extruder
  • Mould
  • Vacuum Calibrating tank
  • Hauling off machine
  • Printing machine
  • Pipe cutting machine
  • Pipe pile-up frame
  • Auxiliary machines (feeding, belling and crushing)
Key Features
  • Equipped with imported temperature controllers and inverters/converters
  • Hardened gear reducer box with carburized and ground teeth
  • Forced cooling system for high-performance, low noise, and long service life
  • Dual material feeding designs (slotted bushing and smooth grooves)
  • Screw and barrel made of nitrided 38CrMoALA for wear and corrosion resistance
  • Available in exhaust-type extruder configurations
PE Single Wall Corrugated Pipe Production
Specialized line for PE single wall corrugated pipes (compatible with PP and PVC materials). Pipe diameter range: 8mm, 12mm, 16mm, 20mm, 25mm, 32mm.
Process Flow
Dryness loader → Single screw extruder → Die → Forming moulds → Water tank (optional) → Haul off and cutter (optional) → Double working-station winder
Technical Specifications
Type Pipe Diameter (mm) PVC Output (kg/h) PE/PP Output (kg/h) MAX Speed (m/min) Total Power (KW)
WR-160 90-160 150-250 200-300 6.0 9.7
WR-250 110-250 250-350 250-350 5.0 8.6
WR-500 200-400 650-750 250-500 3.0 16.9
WR-800 500-800 --- 1000-1100 3.0 16.9
WR-1200 800-1200 --- 1000-1200 1.0 30.0
Model LB110 LB250 LB315 LB400
Pipe Range 20-110mm 75-250mm 110-315mm 180-400mm
Screw Model SJ65 SJ75 SJ75 SJ75
Motor Power 55KW 90KW 132KW 160KW
Output 150kg 220kg 400kg 600kg
Single Screw Extruder Machine
Plastic Water Supply PE HDPE PP PPR Pipe Tube Single Screw Extruder Production/Extrusion Line/Making Machine 0
Crafted with top brand components to ensure production stability, efficiency and machine durability. Features international standard single screw and barrel with strong rigidity ensuring long service life and distinguished plasticizing effect.
Mould System
Plastic Water Supply PE HDPE PP PPR Pipe Tube Single Screw Extruder Production/Extrusion Line/Making Machine 1
Spacious flow channel design guarantees high extrusion capacity and good melting effect. Manufactured and inspected by experienced technicians with optimized temperature control and flow channel design for precise melt temperature control.
Vacuum and Cooling Tank
Plastic Water Supply PE HDPE PP PPR Pipe Tube Single Screw Extruder Production/Extrusion Line/Making Machine 2
Constructed from stainless 304 steel with excellent vacuum system for precise pipe sizing. The holder in the first step guarantees proper pipe shaping and provides extra power for pipe movement.
Haul-off Unit
Plastic Water Supply PE HDPE PP PPR Pipe Tube Single Screw Extruder Production/Extrusion Line/Making Machine 3
Belt system ensures produced pipes run stably and steadily. Unique mechanism prevents pipe ovality while specialized belt design assures proper pulling without slippage.
Cutting Unit
Plastic Water Supply PE HDPE PP PPR Pipe Tube Single Screw Extruder Production/Extrusion Line/Making Machine 4
Offers two cutting methods including rapid cutter and planetary cutter. Cutting method can be switched randomly according to produced pipe material requirements.
Tipping Rack
Plastic Water Supply PE HDPE PP PPR Pipe Tube Single Screw Extruder Production/Extrusion Line/Making Machine 5
Automatically tilts to stack pipes neatly, reducing manual handling and ensuring safe, efficient collection of products during continuous production operations.
After-Sales Services

During machine production, we provide regular photo updates on equipment status. Upon completion, we arrange trial tests and invite buyers to inspect the machine at our factory.

We handle all shipping documentation and logistics. Our engineers provide on-site installation, commissioning, and worker training services.

We offer 18-month warranty from shipment date and lifelong technical support for production guidance.

For more information about our HDPE pipe extrusion line, please contact us for detailed specifications and pricing.
