Low Noise PPR Pipe Extrusion Line 50mm High Production

Certification
China Zhangjiagang Langbo Machinery Co. Ltd. certification
China Zhangjiagang Langbo Machinery Co. Ltd. certification
I'm Online Chat Now

Low Noise PPR Pipe Extrusion Line 50mm High Production

Low Noise PPR Pipe Extrusion Line 50mm High Production
Low Noise PPR Pipe Extrusion Line 50mm High Production Low Noise PPR Pipe Extrusion Line 50mm High Production Low Noise PPR Pipe Extrusion Line 50mm High Production Low Noise PPR Pipe Extrusion Line 50mm High Production

Large Image :  Low Noise PPR Pipe Extrusion Line 50mm High Production

Product Details:
Place of Origin: ZHANGJIAGANG
Brand Name: LB
Certification: CE / ISO
Model Number: LB
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Packaging Details: NORMAL PACKAGE
Delivery Time: 45 WORKING DAYS
Payment Terms: L/C, T/T,
Supply Ability: 15 SETS PER MONTH

Low Noise PPR Pipe Extrusion Line 50mm High Production

Description
Production Name: PPR Glassfiber PPR Pipe Production Machine Pipe Size: 20-63mm; 3 Layer
Extruder Capacity: 350kgs/h For Inner &outer +180kgs/h Middle GF Die Head: 3 Layer Co-extrusion With Two Extruders
Production Speed: 12m/min; 20m/min; 28m/min Control System: SIEMENS PLC With Remote Control System
High Light:

Low Noise PPR Pipe Extrusion Line

,

PPR Pipe Extrusion Line High Production

,

50mm Pipe Extrusion Line



High production Low Noise PPR Pipe Extrusion Line



APPLICATIONS OF PPR PIPES:

PP-R pipe are commonly used for ducting hot water. The main reason is that it has good thermal resistance and thermal insulation effect. Moreover, PP-R pipes also have great elasticity and easy assembly characteristics.
As the increasingly demand of PP-R pipes, LANGBO Machinery developed high-efficiency and high-stability PP-R pipe extrusion line. It obtained great quality and high efficiency to meet the needs of world’s market.

Low Noise PPR Pipe Extrusion Line 50mm High Production 0

SHORT DESCRIPTION FOR PRODUCTION LINEAS:

* SJ series high efficient single screw PE pipe extruder is developed by our company adopting German latest advanced technology. Screw is optimization that composing separate type screw with mixing parts. Barrel is optimization that composing groove barrel with lengthened feeding segment. There are advantages as following by combining separate type screw with groove barrel:

* It's optimized in the whole material melting process. By this way, we can get more extrusion throughput. It is achieved that the extruding material melt in a much lower temperature.

* Cutting function is produced through separate clearance and makes raw material equally. It is controlled in the melt plasticization process. Therefore, the granules that have a smaller separate clearance can enter the melting channel.

* It has a wide manufacturing range for different materials. It is suitable for all kinds of polyolefin materials and especial for materials as HDPE, PP and PPR pipes.



                                        Low Noise PPR Pipe Extrusion Line 50mm High Production 1

FEATURES:

LANGBO Machinery not only provides suitable PP-R extrusion equipment, but also offers the necessary accessories such as Laser printer, drying and precise dosing systems for the pipe diameters from OD20mm to OD160mm, which are commonly used in the market. According to the market requirements, LANGBO Machinery has developed single-layer, three-layer or even multi-layer PP-R pipe production line, providing professional design and complete production equipment solution.
