Fireproof 55KW WPC Profile Extrusion Decking Boards Making Line
Product Details
| EXTRUDER MODEL: | CONICAL TWIN SCREW EXTRUDER | PROFILE'S SIZE: | 1240MM |
|---|---|---|---|
| MOTOR POWER: | 55KW | RAW MATERIAL: | WPC & ADDITIVES |
| CUTTER: | SAW CUTTER | CAPACITY: | 300-350KG/H |
| Highlight |
WPC Decking Boards Making line,55KW WPC Profile Extrusion line,Fireproof WPC Profile Extrusion line |
||
Product Description
Fireproof WPC Decking Boards Making line
SPECIFIC LINE FOR WPC
WPC profile extrusion line is adopted specially designed screw, barrel, mould and unique WPC craft and formula initiated by our company. The WPC extruder can match with the auxiliary machines and moulds perfectly. The whole production line is of automatic control from the loading to the final discharging. The machines can also be manually adjusted separately. With the advantages of good plastication, low energy-consumption, high output, excellent performance, long endurance, etc.
It can be equipped with relative auxiliary equipment, such as vacuum calibration platform, haul-off machine, cutting machine and material stacker. It is mainly used for extruding outdoor decorative WPC profiles, such as gardening landscapes, outdoor landscapes, pallets, etc.
MATERIALS
Different materials hold different advantages. PVC is the most common type of plastic used for plastic profiles due to its flexibility,allowing it to be used for numerous applications.
Plastic wpc profile extruded with LANGBO MACHINERY technology are available in a wide range of shapes and sizes including shapes such as thin film,rods,wire sheets,trim, channels,rods,tubing and gaskets additional saving energy up to 50％
DESIGN
We design our profile extrusion line with the same goals every day:
development of solutions that solve the everyday problems of people working in this sector;
efficiency and reduction of energy consumption and production scraps;
enhancing of our systems,ensuring their Iasting life cycle;
electronic simplification of machine control panels,to make them easy to use also by unspecialised operators.
SPECIFICATION:
The Table provides a general information for standard Product.
For Further customized technical assignment please contact us.
| Model | SJZ45 | SJZ51 | SJZ65 | SJZ80 | SJZ92 |
| Screw diameter (mm) | 45/100 | 51/105 | 65/132 | 80/156 | 92/188 |
| Screw rotation speed (r/min) | 4-45.5 | 1-30 | 1-34.7 | 1-36.9 | 1-32.9 |
| The effective length of the screw (mm) | 1000 | 1050 | 1430 | 1800 | 2520 |
| Main motor power (kW) | 15 | 22 | 37 | 55 | 90 |
| Barrel heating power (kW) | 12 | 18 | 24 | 36 | 48 |
| Capacity (kg/h) | 95 | 110 | 250 | 380 | 520 |
| Central height (mm) | 1000 | ||||
| Net Weight(kg) | 3000 | 3200 | 5000 | 6500 | 7500 |
Product Highlights
