ABB PVC Foam Board Sheet Extrusion Line Flame Retardant

ABB PVC Foam Board Sheet Extrusion Line Flame Retardant
ABB PVC Foam Board Sheet Extrusion Line Flame Retardant ABB PVC Foam Board Sheet Extrusion Line Flame Retardant ABB PVC Foam Board Sheet Extrusion Line Flame Retardant

Large Image :  ABB PVC Foam Board Sheet Extrusion Line Flame Retardant

Product Details:
Place of Origin: ZHANGJIAGANG
Brand Name: LB
Certification: CE ISO
Model Number: LB
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: USD EUR
Packaging Details: NORMAL PACKAGE
Delivery Time: 30 WORKING DAYS
Payment Terms: L/C, T/T
Supply Ability: 15 SETS PER MONTH

ABB PVC Foam Board Sheet Extrusion Line Flame Retardant

Description
Condition: New Inverter: ABB
Screw Design:: Double Screw Voltage: 380V, 50Hz, 3phase
Type: PVC Foam Board Making Machine Power(W): 110kw
High Light:

Flame retardant PVC Foam Extrusion Line

,

ABB PVC Foam Board Extrusion Line

,

PVC Foam Sheet Extrusion Line

Flame-retardant PVC Foam Board Extrusion Line

INTRODUCTION

PVC Foam Board Making Machine also names PVC foam board extrusion line which is used plastic extrusion manufacturing process to make PVC foam board, furniture foam board, and construction board.

LANGBO MACHINERY is a professional PVC foam board machine manufacturer in China, who can produce PVC board making the machine with stable properties and excellent quality with affordable prices. LANGBO MACHINERY plastic machine manufacturer not also can supply its project report which you want to know more about the machine as well as the investment, after buying our machine, we can also delegate staff to install the machine for making PVC board.

PVC foam board can be used as furniture board and construction board, as it is lighter and cost price is much cheaper comparing to wood, and we also can protect the environment for our world.

LANGBO MACHINERY PVC foam board machine can produce 1200mm width and 5-20mm thickness board, the customer can customize the thickness as their market demands, our machine is consist of main extruder, T-die, calibration table with foaming mold, cooling bracket, film laminator, cutting machine and stacker.

LANGBO MACHINERY PVC foam board production line also can be used to produce solid PVC sheet after changing the T-die and downstream machine, the PVC sheet also to be used in furniture as well as indoor flooring.

                                                    ABB PVC Foam Board Sheet Extrusion Line Flame Retardant 0

EXCELLENT PROPERTIES

· Excellent chemical resistance

· High strength-to-weight ratio

· Flame resistance, among others.

                                                   ABB PVC Foam Board Sheet Extrusion Line Flame Retardant 1

FOAM BOARD PROCESS FLOW

For Foam Board Production Line the general processing step can be like this:

Mixing--Feeding---Extrusion----Forming and Cooling----Cooling---Hauling off -- Cutting



                                                   ABB PVC Foam Board Sheet Extrusion Line Flame Retardant 2

PRODUCT DESCRIPTION

Product name PVC Foam Board / PVC Foam Sheet
Thickness 1-25mm
Size 1220*2440mm, 1560*3050mm, 2050*3050mm, or customized
Density 0.43-1.05g/cm3
Feature Sound insulation, Heat insulation, Moistureproof, Waterproof



COMPONENT OF WPC/PVC FOAM BOARD PRODUCTION LINE

No Name Type Quantity
1. 500/1000 hot and cold mixer SRL-Z500/1000 1set
2. 200/500 hot and cold mixer SRL-Z200/5000 1set
3. Automatic feed loader ZJF500 1 set
4 Conical twin screw Extruder SJSZ80/156 1 set
5. Conical twin screw Extruder SJSZ65/132 1 set
6. Mould / 1 set
7 Calibration platform ZKDX-1220 1 set
8 Bracket TJ-2000 1 set
9

First Haul off machine

Edge cutter

SLQ -1220 1 set
10. Cross cutter HQG-1220 1 set
11. Stacker BFL-1220 1 set
12. Crusher SWP400 1 set
13 Miller SMF-400 1 set





SPECIFIC SPECIFICATION
1 Main motor frequency controller : siemens or ABB
2 Temperature controller : OMRON or RKC
3 AC controller : Schneider or simens(As customer requirement)
4 Thermal overload relay : Schneider
5 Switch : DELIXI or Schneider
6 All electrical units on components from standard companies like OMRON/RKC/Siemens
