UV-50W Laser Printer For Customizable Printing On Pipe Fittings SIEMENS Motor

Code Laser Printer/Pipe Fitting Laser Printer/UV-50W Laser Printer/Corruagated Pipe Laser Printer​

F series fiber laser inkjet printer
F series fiber laser jet code is the most advanced in the world Laser marking, spray code equipment. It can be widely used in all kinds of flowing water Line flight marking and tell static marking industry, can meet a variety of High precision,high efficiency laser marking needs,using the world leader First level fiber laser and imported parts,marking accuracy High speed,stable performance,life up to 100000 hours.

Technical features
Fully sealed integrated light source,free from external dust and machinery Under the influence of vibration, the light quality is more stable; The electro-optic conversion rate is as high as 60%. without power coupling loss,The power consumption of the whole machine is 300W,and there is no consumables,which is obviously reduced for customers Low operating cost; Embedded operating system,intelligent man-machine platform,accurate Touch control makes the machine as convenient as a mobile phone; Online editing function, super long information editing, meter length counting Adjustable degree,synchronization and one key reset function,to meet the needs of profile customers Functional reauirements.
High speed jet printing calculation mode, online printing speed is higher than 120m/min.

Application
It is widely used in pipes, building materials, profiles, adhesive strips, electronic products, winem food and other industries, suitable for all kinds of plastic, metal, rubber and other materials laser marking.

Product Parameters

Laser output power	10W/20W/30W/50W
Mode of operation	Pulsed
Pulse width, (FWHM)	100 ns
Typical beam quality, M2	<2
Central emission wavelength	1064 nm
Cooling type	Air cooling
Pulse repetition rate*kHz	20-100
Net dimensions	110mmx110mm
Marking line speed	<12000mm/s
Marking depth	<0.4mm
Marking line width (Min.)	0.01mm
Max. power consumption	500W
Operation temperature & humidity	0-40ºC, 45-85% (no condensation
