PVC Single Wall Corrugated Plastic Pipe Extruder Production Machine
Short desciption
Our Single Wall corrugated pipe machine consists of Extruder, Mold Blocks, Corrugated Forming Machine, Cooling Equipment,Counting Machine and Auto winding system. It can continuously produce many kinds of diameter single wall corrugated pipes in high speed.
Features
series single screw extruder
Mould for precise pipe shaping
Vacuum cooling tank for rapid cooling
Spray cooling tank for larger pipes
Haul-off machine for continuous production
Cutting machine for accurate pipe length
Stacker for organized storage
Producting process
PVC powder + additive — mixing—material feeder—twin screw extruder—mould and calibrator—vacuum and cooling tank—spraying cooling machine—haul-off machine—cutting machine—discharge rack or pipe belling machine.
Specifications:
MODEL | PIPE DIAMETER (MM) | EXTRUDER MODEL | MOTOR POWER (KW) |
LB-32F | 16-32 (FOUR PIPE) | SJSZ65/132 | 37 AC |
LB-32E | 16-32 (DOUBLE PIPE) | SJSZ51/105 | 22 AC |
LB-32W | 16-32 (DOUBLE PIPE) | SJSZ65/132 | 37 AC |
LB-40E | 16-40 (DOUBLE PIPE) | SJSZ51/105 | 22 AC |
LB-40W | 16-40 (DOUBLE PIPE) | SJSZ65/132 | 37 AC |
LB-50E | 16-50 (DOUBLE PIPE) | SJSZ51/105 | 22 AC |
LB-50W | 16-50 (DOUBLE PIPE) | SJSZ65/132 | 37 AC |
LB-63W | 16-63 (DOUBLE PIPE) | SJSZ65/132 | 37 AC |
Product detail
1. Raw Material Feeding
- PVC resin and additives are mixed and fed into the hopper of the extruder.
2. Melting & Extrusion
- The material is heated and melted in the screw extruder(single or twin-screw) to form a homogeneous molten PVC.
3. Pipe Molding (Corrugation Forming)
- The molten PVC is pushed through a die head to form the initial pipe shape.
- The pipe enters the corrugator mold, where vacuum suction and cooling shape the outer corrugations while maintaining a smooth inner wall.
4. Cooling & Solidification
- The pipe passes through a water cooling tank or spray cooling system to harden the structure.
5. Traction & Cutting
- An automatic haul-off unit pulls the pipe at a controlled speed.
- A cutting device(saw or guillotine cutter) trims the pipe to the required lengths.
6. Stacking & Packaging
- Finished pipes are collected and packed for storage or shipment.
