Product Details:
|
| Pipe Diameter: | 16~800mm | Contactor Brand: | Siemens |
|---|---|---|---|
| Capacity: | 120~800kg/h | Delivery Time: | 45days |
| Install Power: | 37~600kw | Extruder: | Single Screw Extruder |
| High Light: | pipe expander machine,pvc pipe socketing machine |
||
Single Screw PE HDPE Plastic Tube Extrusion Machines For Water Hose Pipe Making
PE HDPE water hose pipe Making Machine / extruder production line
Details:
| Condition: | New |
| Application: | Energy Supply Pipe |
| Power(W): | 37KW |
| Certification: | CE ISO9001 |
| Pipe Diameter: | 16~800mm |
| Raw material: | PE grain |
| Produce area: | China |
| Type: | Pipe Production Line, PE Pipe Extrusion Production Line |
| Production Capacity: | 90% |
| Model Number: | GFE-PE |
| Dimension(L*W*H): | 25 * 4 * 4M |
| Warranty: | 13 months |
| Extruder: | Single screw extruder |
| Delivery time: | 30 DAYS |
| Certificate: | ISO9001, CE, SGS |
| Pipe Material: | PE |
| Place of Origin: | Jiangsu, China (Mainland) |
| Voltage: | 3PHASE 380V 50HZ |
| Weight: | 6T |
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Central height: | 1000mm |
| Capacity: | 120~800kg/h |
| Contactor Brand: | Siemens |
Working flow:
Mixer→ Vacuum feeding →Material dry → Single screw extruder →Marking line extruder(co-extrusion)→Vacuum calibration spraying cooling tank → Spraying cooling tank→ Color-ribbon printer → Haul-off machine →Cutter →Stacker
Main technical parameter of HDPE pipe production line/ PE Pipe extrusion line:
| Item: | SJGF75 | SJGF160 | SJGF250 | SJGF450 | SJGF630 | SJGF800 | SJGF1000 |
|
Diameter (mm): |
20-75 | 63-160 | 75-250 | 160-450 | 315-450 | 400-800 | 500-1000 |
| Main machine: |
SJ25/25 SJ65/33 |
SJ25/25 SJ65/33 |
SJ25/25 SJ75/33 |
SJ25/25 SJ90/33 |
SJ25/25 SJ120/33 |
SJ150/33 | SJ150/33 |
|
Max. capacity (kg/h) |
120-150 | 120-300 | 280-400 | 500-700 | 700-900 | 900-1200 | 900-1200 |
|
Total power (KW): |
110 | 130 | 260 | 400 | 500 | 600 | 600 |
If you want more details of our HDPE pipe machine/ HDPE pipe making machine, please let us know!
| Packaging Details: |
Package for PE Pipe Extrusion Production Line. Body Covered by PE shrink film. Bottom with wooden pallet. Wooden box for moulds. |
| Delivery Detail: | 30 days for PE Pipe Extrusion Production Line |
Our Service:
After the machine is finished before delivery, we will notice the cutomer to check the trial. Machine arrives in customer'sfactory, if need, we will send the engineer to install the machine, debug the machine and train the worker.
Warranty time: one year.
Come to joint us, everything will be make you satisfied, if you don't believe, let us test now! O(∩_∩)O, waiting for you!
Application of PE pipe:
1.Urban tap water pipe network system
Large diameter PE pipe, health non-toxic, not fouling, more suitable for urban water supply main conduit and buried tube, safety, hygiene, convenient construction.
2. Agriculture irrigation pipe
PE pipe inside sleek, great flow, cross road construction, good impact resistance, it is the ideal tool for agricultural irrigation.
3.Industrial materials duct
Chemical industry, chemical fiber, food, forestry, pharmacy, light industry and papermaking, metallurgical and other industrial raw material conveying pipe.
4.Landscaping water supply network
Landscaping need lots of water pipe, PE pipe toughness and low cost, make it become the best choice.
5.Sewage discharge pipes
PE pipe have unique corrosion resistance, can be used in industrial wastewater, sewage discharged pipe, low costs and maintenance costs .
Company Introduction:
ZHANGJIAGANG LANGBO MACHINERY CO., LTD locates in Zhangjiagang city, which takes 2 hours by car from Shanghai & 40minutes from WUXI airport.
Our company is mainly supply various kinds of plastic machinery, such as plastic washing recycling machines, plastic granulating machine, plastic pipe extrusion machine and related auxiliary equipments. Based on more than 20 years experience and constant efforts in this field, we have gained much experience and professional technology on the solutions from technical design to extrusion manufacturing.
What we can promise is to offer customers high quality machines at competitive prices with positive after-sales service anytime.
