3kw Plastic Automatic Pipe Winding Machine / Pipe Winder Single Plate Or Double Plate
Product Details
| Voltage: | 220-415V | Weigh: | 1500kg |
|---|---|---|---|
| Winding Pipe Diameter: | 16-110mm | Condition: | New |
| Power: | 3kw | Item: | Pipe Coiling Machine |
| Product Type: | Plastic Pipe | Plate: | Single Plate Or Double Plate |
| Highlight |
pipe expander machine,pvc pipe socketing machine |
||
Product Description
3kw Plastic Automatic Pipe Winding Machine / Pipe Winder Single Plate Or Double Plate
Features and Application:
1. Winding machine, automatic winding machine, coil winding machine,
2. The machine is mainly used in winding and packing of plastic pipes, aluminum-plastic compound pipe,
cross-linking compound pipe and other plastic soft pipes.
3. The plate is controlled by gas; winding adopt torque motor; with special equipment to arrange the pipe, this
pipe coiling machine can wind pipe well, and work much stable.
4. It adopts automatically winding, adjusting winding speed and winding method.
5. It has two disks for continuous winding. It adopts pneumatic method. The wheel rib of the winding up wheel
adopts pneumatic opening and closing. It is equipped with a ray creel stand to automatically wind
displacement. It reaches winding up orderly. The machine structure is compact. Its automatication is high. Its
appearance is beautiful and its operation is convenient.
Main technical parameters:
| Model | DPS-32(single) | SPS-32(double) | DPS-63(single) | SPS-63(double) | DPS-110(single) |
| Inner diameter of coil: | 450-800mm | 450-800mm | 550-1500mm | 550-1500mm | 800-2000mm |
| Winding Speed: | 0.5-40m/min | 0.5-40m/min | 0.5-40m/min | 0.5-40m/min | 0.5-10m/min |
| Winding Width: | 300-500mm | 300-500mm | 300-500mm | 300-500mm | MAX 700mm |
| Max winding pipes: | Ø16-32mm | Ø16-32mm | Ø20-63mm | Ø20-63mm | Ø75-110mm |
| Air Pressure: | 0.6mpa | 0.6mpa | 0.6mpa | 0.6mpa | 0.6mpa |
| Moment Motor: | 10N.M | 10N.M | 25N.M | 25N.M | 60N.M |
| Reduction Box: | WPA100 | WPA100 | WPA120 | WPA120 | WPA150 |
| Cylinder Model: | SC 50×75 | SC 50×75 | SC 50×75 | SC 50×75 | SC 80×100 |
| Clutch: | M3-25A | M3-25A | M3-40A | M3-40A | M3-60A |
| Winding displacement: | GP40 | GP40 | GP40 | GP40 | GP50 |
| Dimension: | 1800x1450x1500 | 2800x1700x1800 | 2300x1550x2200 | 3000x2800x2000 | 3600x2100x3300 |
| Weight: | 600KG | 800KG | 800KG | 1500KG | 3000KG |
Our Advantages:
High quality
Reliable, Durable
Reasonable and competitive price
Good after-sale service & within 12hours replying by email
One year guarantee
More than 15 years of experience
Our Services:
Engineers available to service machinery overseas.
Warranty:
One year after B/L date.
If the equipment fails due to the quality of the machine during one year, we will provide replacement and the
repair Free of Charge. After One Year customer must pay for Spare Parts, we will provide long-term technical
assistance.
Workers must operate the machines according to the design of the machine. XINYAO Machinery will not be
responsible for accidents which are caused by improper operation of workers.
What can we bring you?
1. High-quality equipment and highly competitive market prices can bring you more profits.
2. More than 15 years of plastic extrusion machine industry experience, can solve the various problems in the work. Improve machine efficiency for you.
3. More than 15 years of plastic extrusion machine industry experience, has a good supply system, can provide you one-stop service with the pre-sale, sale and after sale service. Save your purchasing cost and maintenance costs.
