PP PE Films Strand Plastic Pelletizing Machine Single Screw Double Stage Pull Strap

1 SET
MOQ
USD, EUR
Price
PP PE Films Strand Plastic Pelletizing Machine Single Screw Double Stage Pull Strap
Features Gallery Product Description Request A Quote
Features
Specifications
MOQ: 1SET
Screw Diameter(mm): 85-180
Output(kg/h): 120-180
Name: PET Recycling Line
Supply Ability: 50sets/year
Packaging Details: Standard Sea Worthy Packing
Highlight:

pet recycling machine

,

pet plastic recycling machine

Basic Infomation
Place of Origin: ZHANGJIAGANG
Brand Name: LB
Certification: CE, ISO
Model Number: LB
Payment & Shipping Terms
Packaging Details: STANDARD PACKAGE
Delivery Time: 60 WORKING DAYS
Payment Terms: L/C, T/T
Supply Ability: 10 SETS PER MONTH
Product Description





PP PE Films Strand Plastic Pelletizing Machine Single Screw Double Stage Pull Strap





Two stages with pull strap pelletizing method







Application:





1. Applicable plastic materials: BOPP, CPP, HDPE, LDPE, LLDPE, PET, PA, EPE, etc



2. Applications: for recycling printed and heavily contaminated film materials



3. Material types:woven bag,printed LDPE film,film(rolls,loose,bundled),agricultural film waste,foamed



plastic(EPE) and raffia.



4. Material is cut, pre-dried, pre-heated, pre



homogenized and compacted in the shredding drum.



5. Less power consumption cost per kilogram,high throughput,reduced floor space occupation and operator



attendance.







Pelletizing method: pull strap pelletizing





Pull Strip Cutting Pelletizing Machine process:





Belt conveyor → Metal detector →Film agglomerating → Single screw extruder → Hydraulic screen changer



→ Mould die→ Water Tank→ Gale dryer→ pelletizer →air feeding& Silo storage → Finished product packing.







Main Technical Parameter:





Model ML85 ML100 ML130 ML160 ML180
Screw diameter(mm) 85 100 130 160 180
L/D for the first stage 30 30 30 30 30
L/D for the second stage 10 10 10 10 10
Output(kg/h) 120-180 200-350 400-550 600-800 800-1000







Pull Strip/strand Cutting Pelletizing Machine with Strip cutting system: we can design it to



horizontal or vertical type water ring die-cutting system as per your raw material.







Turnkey project service:





1. We will provide all the machines for the complete production according to customer's requirements.



2. We will provide complete service for factory layout and other information to help customers to build the



factory.



3. We will provide good service for machine installation and training until the customers can run the machines



and make stably production.



4. Except for a one-year quality guarantee, we will provide after-sell service for all life.



5. For long-term cooperation, we always provide good quality, good price, and good service to customers.







We are a professional and trustable supplier for turnkey projects. Let us do win-win business together!
