Product Details:
|
| Automatic Grade: | Full Automatic | Application: | Pipe |
|---|---|---|---|
| Condition: | New | Certificate: | CE ISO9001 |
| Color: | According To Customer's Requirement | Feed Model: | One Feeder |
| Frequency Control: | ABB | Temperature Controller: | Omron |
| Highlight: | single screw extruder machine,extruder plastic machine |
||
Water Pe Pipe Extrusion Line , Ppr Pp Single Screw Plastic Extruder Making Machine
Product Feature:
1) Single screw extruder
adopts long L/D, high efficiency screw, high extrusion capacity, uniformed plasticization. Extruder and haul off
machine motors adopt imported AC/DC inverter as speed regulators.
2) Pipe die head
Inner heating system, high efficient, easy extrusion. Bronze calibrators can make the pipes fast calibrated and
cooled.
3) Vacuum calibrating tank and cooling tank
adopts advanced water circulation, high pressure cooling system, installed with vacuum degree adjusting
device and automatic water temperature and water level controlling system.
4) Haul off machine
adopts caterpillar type: 2-claw, 3-claw, 4-claw, 6-claw, 8-claw, 10-claw etc, suitable for different sizes of pipes.
5) Cutting machine
Dust-free cutter or planetary cutter can be applied, accurate cutting, reliable property, high efficiency. ABB
inverter, meter-counter or travel switch is adopted.
Description:
1. PE Water and Gas Plastic Pipe Production Line/pe plastic pipe production line/plastic pipe aking machine is
mainly designed specially for polylefin, polythylene pipe processing and suitable for PE PP PB PPR pipe high-
speed extrusion.It adopts rugged compact reducer,shielding type separation screw,slot barrel,basket type
extrusion die etc,which ensure the users can make high quality plastic pipe.
2. Process flow
Raw material + additive → mixing → vacuum feeding machine → hopper dryer → single screw extruder →
color code extruder → mould and calibrator → vacuum forming machine → cooling tank → haul off machine
→ cutting machine → discharging rack
Main technical parameter of HDPE pipe production line/ PE Pipe extrusion line
| Model number | Pipe diameter (mm) | Max output (kg/hr) | Production rate (m/min) | Extruder model | Installation power | Layout dimension |
| PE16/63 | 16-63 | 150 | 1-15 | SJ65/30 | 85kw | 35x3x2m |
| PE20/110 | 20-110 | 200 | 1.2-12 | SJ65/33 | 110kw | 38x3.1x2.2m |
| PE50/160 | 50-160 | 350 | 0.6-8 | SJ75/33 | 125kw | 38x3.1x2.2m |
| PE75/250 | 75-250 | 350 | 0.5-4 | SJ75/33 | 180kw |
|
Why choose us:
Equipment warranty
1. About the equipment, Middle tech promised the good quality of 12 month.
2. during the warranty, no purposely and artificially damage change the damaged part, we will free
maintenance and technical services.
3. Over 12 months, Buyer's needs to pay the producing cost of the worn part, and life-long supply the part of equipment and freely device
