16-160mm Vacuum Tank PP-R Pipe Machine Vacuum Calibrating For Plastic
Product Details
| Condition: | New | Automatic: | Full Automatic |
|---|---|---|---|
| After Sales Service: | Engineer Overseas Service | Application: | Pipe |
| Screw Design: | Single-screw | MATERIAL: | PPR PE PP PVC |
| Highlight |
ppr pipe production line,cpvc pipe making machine |
||
Product Description
16-1600mm Vacuum Tank PPR Pipe Production Line Vacuum Calibrating For Plastic
Quick Detail of PPR pipe production line vacuum tank:
Vacuum Calibration Tank For Pipes
1.Pipe range:16-2000mm
2.Power of water pumps:3-8*7.5kw
3.Power of vacuum pumps:2.2-6*5.5kw
Description of PPR pipe production line vacuum tank:
1,Mainly used for PE, HDPE plastic pipe vacuum moulding and cooling.
2,Vacuum sizing tank and waterway system are optically designed and made of stainless steel.
3,water system and the vacuum system are stable and can be adjusted.
4,Vacuum tank can be adjusted levelly and vertically.
Applications of PPR pipe production line vacuum tank:
The vacuum calibrating tank is a necessary part in pipe production line.
It can help pipes form stable and fast.
The vacuum calibrating tank is of high quality and easy operation.
We have many diffierent types of vacuum calibrating tank for customers to make a proper choice
Specifications of PPR pipe production line vacuum tank:
| Model | 63 | 63-s | 125 | 250 | 450 | 500 | 630 | 800 | 1200 | 1400 | 1600 | 2000 |
| Pipe range(mm) | 16-63 | 16-63 | 32-125 | 63-250 |
110- 450 |
160- 500 |
250- 630 |
315-800 | 630-1200 | 710-1400 | 1000-1600 | 1400-2000 |
| Water pumps(kw) | 3 | 2*3 | 5.5 | 5.5 | 2*5.5 | 2*5.5 | 2*5.5 | 3*7.5 | 6*7.5 | 6*7.5 | 6*7.5 | 8*7.5 |
| Vacuum pumps(kw) | 2.2 | 2*2.2 | 4 | 4 | 2*4 | 2*4 | 2*4 | 3*5.5 | 6*4 | 6*4 | 6*4 | 6*5.5 |
|
Length of vacuum calibration tank |
6000 | 1500+8500 | 1500+10500 | |||||||||
Competitive Advantage of PPR pipe production line vacuum tank:
1. PPR raw material for elements only carbon and hydrogen elements, without harmful toxic elements, healthy,not only for hot and cold water pipe,
but used in clean drinking water system.
2.Good heating resistance, PPR pipe via soften point of 131.5 degree.the Max working temperture upto 95 degree, the Pipe which used in Water
supply and Drainage up to the construction specification required by Clients.
3.Long service life, PPR pipe in working temperature 70 degrees,working pressure1.0 Mpa, can be up to 50 years, at room temperature 20 degree,
easy installation, connection
4.Recycling the waste PPR material
