Automatic Extrusion Line Recycled For Plastic Pipe Production

Automatic Extrusion Line Recycled For Plastic Pipe Production
Automatic Extrusion Line Recycled For Plastic Pipe Production Automatic Extrusion Line Recycled For Plastic Pipe Production Automatic Extrusion Line Recycled For Plastic Pipe Production

Large Image :  Automatic Extrusion Line Recycled For Plastic Pipe Production

Product Details:
Place of Origin: ZHANGJIAGANG, JIANGSU, CHINA
Brand Name: LB
Certification: CE ISO
Model Number: LB-63W
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: USD EUR
Packaging Details: NORMAL PACKAGE
Delivery Time: 45 WORKING DAYS
Payment Terms: L/C, T/T
Supply Ability: 15 SETS PER MONTH

Automatic Extrusion Line Recycled For Plastic Pipe Production

Description
Name: PVC Pipe Extrusion Line Packaging Details: Film Wraping
Plastic: PVC Application: Pipe Making
Raw Material: Pvc Powder Screw Design: Conical Twin Screw
Material Of Screw: 38CrMoALA Motor: Siemens
Inverter: ABB Temperature Sensor: Omron
High Light:

Automatic Extrusion Line For Plastic Pipe

,

Recycled Plastic pvc Pipe Extrusion Line

PVC Four Strand Pipe Extrusion Line

USAGE OF PIPE WITH SMALL DIAMETER

PVC pipes with a diameter from 16-64 mm are usually applied as wiring conduit pipes in fields of building, architecture, telecom communication, decoration, etc.

Automatic Extrusion Line Recycled For Plastic Pipe Production 0

Four Strand PVC Pipe Extrusion Line by Langbo Machinery

For the Four Strand pipe Extrusion line, LB-32 provides high productivity with the Four Strand model. It produces a pipe diameter in a range of 16-63mm. For the production line with multi-strand, one of the most important points to attention is automatic grade. The Four Pipes should be produced separately. That means, if one strand pipe runs out of control, the other strands should not be affected and extrudes as normal. The internal PLC system helps machines work independently from the pipeline.



FOUR OUTPUT = FOUR TIMES PRODUCTIVITY CAPACITY

For pipe with small diameter, man can choose Four Strand PVC pipe Production line. At the same time, four-pipe extrusion can not only increase productivity but reduce the cost of machines, cost of human consumption and save the space of the factory. For long-time production, man benefits a lot from this kind of four-strand pipe extrusion.

Automatic Extrusion Line Recycled For Plastic Pipe Production 1

SPECIFICATIONS

Production Capacity has a close relationship with screw size and motor power. With the following table, you can get a rough overview to our pipe TWO Strand pipe solution.

MODEL PIPE DIAMETER (MM) EXTRUDER MODEL MOTOR POWER (KW)
LB-32F 16-32 (FOUR PIPE) SJSZ65/132 37 AC
LB-32E 16-32 (DOUBLE PIPE) SJSZ51/105 22 AC
LB-32W 16-32 (DOUBLE PIPE) SJSZ65/132 37 AC
LB-40E 16-40 (DOUBLE PIPE) SJSZ51/105 22 AC
LB-40W 16-40 (DOUBLE PIPE) SJSZ65/132 37 AC
LB-50E 16-50 (DOUBLE PIPE) SJSZ51/105 22 AC
LB-50W 16-50 (DOUBLE PIPE) SJSZ65/132 37 AC
LB-63W 16-63 (DOUBLE PIPE) SJSZ65/132 37 AC
