Product Details:
|
| MOTOR POWER: | 160-210KW | SCREW CONCEPT: | SINGLE SCREW |
|---|---|---|---|
| CAPACITY: | 550KG-600KG | MOTOR BRAND: | SIEMENS |
| GEARBOX BRAND: | FLENDER | WARRANTY: | 12 MONTHS |
| PROCESSING MATERIAL: | PR OR PPR | MACHINE BRAND: | LANGBO |
| High Light: | PE Pipe Single Screw Extruder,210 KW Single Screw Extruder,75/38 High Capacity Single Screw Extruder |
||
75/38 High Capacity PE Pipe Single Screw Extruder
SINGLE SCREW EXTRUDER TYPES:
Extruder has two types including single screw and twin screw extruder. The single screw has simper structure and high output capacity. It mostly has 60/38, 75/38, 90/38, 120/38 and so on.
For the single screw extruder, it has driving motor, gearbox, screw&barrel, control system.
SPECIFICATIONS:
| Model |
Screw diameter (mm) |
L/D |
Rotary speed (rpm) |
Motor power (kw) |
Capacity (kg/hr) |
| SJ25/25 | 25 | 25:1 | 25-130 | 1.5 AC | 1-3 |
| SJ30/25 | 30 | 25:1 | 25-150 | 5.5 AC | 2-8 |
| SJ45/30/33 | 45 | 30:1,33:1 | 8-100 | 7.5 /15 AC | 4-50 |
| SJ65/30/33 | 65 | 30:1,33:1 | 12-150 | 37/55 AC | 50-120/50-250 |
| SJ75/30/33 | 75 | 33:1 | 12-120 | 90 DC | 50-350 |
| SJ90/30/33 | 90 | 33:1 | 10-120 | 90/160 DC | 100-320/100-550 |
| SJ120/30/33 | 120 | 33:1 | 9-90 | 160/250 DC | 200-500/200-800 |
| SJ150/30/33 | 150 | 33:1 | 7-75 | 250/315 DC | 300-800/500-1200 |
