HDPE Pipe Extrusion Line| Uniform Wall Thickness Large Diameter
Product Details
| Extrudertype: | Single Screw Extruder | Cutter: | Planetary Cutter |
|---|---|---|---|
| Type: | SJ-65 SJ-90 SJ-65/33,Extrusion | Coolingmethod: | Water Cooling Tank |
| Pipe Diameter: | 16-160MM | Screwdiameter: | 45mm - 120mm |
| Production Speed: | 1-10m/min | Heatingzones: | 4 - 6 Zones |
| Dragger: | Crawling Traction | Automatic Grade: | Full-automatic |
| Highlight |
HDPE pipe extrusion line with uniform wall thickness,large diameter HDPE pipe extrusion machine,PE pipe extrusion line for uniform thickness |
||
Product Description
Our HDPE Pipe Extrusion Line specializes in producing multi-layer pipes with uniform wall thickness for large diameter applications. This advanced production line utilizes co-extrusion technology to create pipes with functional features while optimizing raw material costs.
Multi-layer pipes are manufactured using co-extrusion pipe line technology. This specialized process enables significant raw material cost savings while producing pipes with enhanced functional characteristics.
- Cost-effective production using recycled materials as middle layers for PE thick wall pipes
- Versatile layer configurations including PP-R layers and structural enhancements like glass fiber reinforcement
- Ideal for hot water supply pipes requiring specialized material properties
PE pipe extrusion lines are engineered for diverse applications including:
- Water supply systems
- Gas distribution networks
- Agricultural irrigation
- Drainage systems
- Cable conduits
- Industrial piping applications
These lines process PE100/PE80 materials with diameters ranging from 16-1200mm, offering excellent chemical resistance, high strength, and consistent quality. All systems comply with ISO and ASTM standards, making them suitable for various infrastructure and industrial applications.
| Model | Pipe Diameter (mm) | Extruder | Extruder Power (kW) | Capacity (kg/hr) |
|---|---|---|---|---|
| LB-63 | 20-63 | SJ65/33 | 55AC | 150 |
| LB-110 | 20-110 | SJ65/33 | 55AC | 150 |
| LB-160 | 75-160 | SJ75/33 | 90AC | 280 |
| LB-250 | 90-250 | SJ75/33 | 110DC | 350 |
| LB-315 | 110-315 | SJ90/33 | 160DC | 450 |
| LB-450 | 160-450 | SJ90/33 | 160DC | 450 |
| LB-630 | 315-630 | SJ120/33 | 280DC | 850 |
| LB-800 | 500-800 | SJ150/33 | 315DC | 1100 |
| LB-1200 | 710-1200 | SJ150/34 | 400DC | 1350 |
