PE Pipe Extrusion Line Customizable Molds Reducing Equipment Failures
Product Details
| Coiling Speed: | 0.1-10m/min | Matieral: | PE Granule |
|---|---|---|---|
| Weight: | 3000kg | Packages: | Exported Standard Packing |
| Gearbox: | Integrated Gearbox | Powersupply: | 380V, 50Hz, 3 Phase |
| Side Line Extruder: | 25/25 1.5kw | Total Length: | Around 30m |
| Heatingzones: | 4 - 6 Zones | Pipediameterrange: | 16mm - 630mm |
| Highlight |
customizable PE pipe extrusion line,PE pipe extrusion molds,reliable PE pipe extrusion equipment |
||
Product Description
Our PE Pipe Extrusion Line features customizable molds designed to significantly reduce equipment failures while optimizing production efficiency. This advanced system enables the manufacturing of high-quality multi-layer pipes through specialized co-extrusion processes.
Multi-layer pipes are produced using our co-extrusion pipe line technology, which employs specialized craft processes to reduce raw material costs while creating pipes with enhanced functional characteristics.
- Cost-effective production using recycled materials as middle layers for PE thick wall pipes
- Versatile layer configurations including PP-R and glass fiber reinforcements for hot water supply pipes
- Enhanced application features through customized layer structures
PE pipe extrusion lines are engineered for diverse applications including water supply systems, gas distribution, agricultural irrigation, drainage systems, cable conduits, and industrial piping. These systems process PE100/PE80 materials with diameter ranges from 16-1200mm, delivering exceptional chemical resistance, high strength, and consistent quality that complies with ISO and ASTM standards for various infrastructure and industrial applications.
| Model | Pipe Diameter (mm) | Extruder | Extruder Power (kW) | Capacity (kg/hr) |
|---|---|---|---|---|
| LB-63 | 20-63 | SJ65/33 | 55AC | 150 |
| LB-110 | 20-110 | SJ65/33 | 55AC | 150 |
| LB-160 | 75-160 | SJ75/33 | 90AC | 280 |
| LB-250 | 90-250 | SJ75/33 | 110DC | 350 |
| LB-315 | 110-315 | SJ90/33 | 160DC | 450 |
| LB-450 | 160-450 | SJ90/33 | 160DC | 450 |
| LB-630 | 315-630 | SJ120/33 | 280DC | 850 |
| LB-800 | 500-800 | SJ150/33 | 315DC | 1100 |
| LB-1200 | 710-1200 | SJ150/34 | 400DC | 1350 |
