Double Screw Extruder Plastic Recycling Pellet Machine 100-1000kg / Hr Capacity
Product Details
| Material: | PE, PP, ABS, AS, PA, EVA, PET | Capacity: | 100-1000kg/hr |
|---|---|---|---|
| Screw L/D: | 44:1 | Screw RPM: | 400-600 |
| Warranty: | 1 Year | ||
| Highlight |
pet recycling machine,pet plastic recycling machine |
||
Product Description
Double Screw Extruder Plastic Recycling Pellet Machine 100-1000kg / Hr Capacity
- Mixing nature-changing: PE,PP,PS+SBS;PA+EPDM;PP+NBR;EVA+Silicon rubber,etc.
PE,PA,PC,CEP+ABS(alloy);PBT+PET;PP+PE,etc.
- Filling nature-changing: PE,PP,EVA etc+aluminum hydroxide,magnesium hydroxide,antimony oxide.
PP,PA,ABS+ferrous powder, sulphuric powder, ceramic powder
- Colored machine pellets: PE,PP,ABS,AS,PA,EVA,PET etc+long fires,small fibres, carbon fibres, crystals and so on, etc.
2. Features of extruder
(1) Barrel
- euro-style rectangle barrl, reflux refrigeration channel is optimized and disposed,which makes temperature difference in D areas smaller.
- innovated design of heater tightened style insures high efficiency of heat transfer and high longevity of heater.
- the material is used high quality nitrided steel ,corrosion proof or antifriction with correspounding process.
(2) screw
---.the screw is made of high tool steel 38 CrMoALA or W6Mo5Cr4V2 by special heat-treatment , which is
possessed with high corrosion-resistat and high functions
(3)metering feeders
- various metering feeders --- single screw ,twin screw ,hollow screw,forced-feeding, side- feeding.
(4) new-style gear transmission system
- new-style project of parallel three-axises driving makes the conve axis,convey
- chain,decelerate and torque get together ,which keep it compact ,and the key bearings are imported
- soakage and spraying lubriation integrate smoothly
- technics,strengthening of tooth face,so they can ensure high torque,high precision and low noise
- the selecte material of drive components is dainty,including super intention alloy cementiteing steel,cementiting and grinding.
(5) electric control cabinet
- frame structure control cabinet
- imported electrical elements
- imported temperature control system
- imported driving system
- interlock and multi-protection
- adopting imported PLC(OMRON or SIMES) to achieve optimized process control. stronger function,steady performance and much higher accurancy
- it can be also accomplished full-set link-lock protection,trouble safeguard,fault alarm cluing and so on
- operation interface on touching screen is visual and marked ,which is brief and easy to use.
(6) pelletizing system
---.various modes of pelletizing,such as water-cooling strand,air-cooling pelletizing,water-ring pelletizing,under water pelletizing
3. Parameter table of twin screw extruder
| Model | Screw Diameter D(mm) | L/D | Screw Rotation N(r/min) | Motor Power P(kw) | Screw Torque T(N.m) | Torque Rating | Output Q(kg/h) | |||
| TSE-75A | 71 | 32-56 | 400 | 90 | 1074 | 4.9 | 250-350 | |||
| 500 | 110 | 1050 | 4.8 | 300-420 | ||||||
| TSE-75B | 71 | 32-64 | 600 | 132 | 1050 | 4.8 | 350-550 | |||
| TSE-75C | 62.4 | 32-64 | 600 | 160 | 1273 | 5.8 | 400-600 | |||
| TSE-75D | 71 | 32-64 | 600 | 200-250 | 1990 | 9.2 | 500-1000 |
|||
