Product Details:
|
| Screw Design: | Single | Automatic Grade: | Full Automatic |
|---|---|---|---|
| Application: | Pipe | Plastic Processed: | PP / PE / PVC |
| Pipe Diameter: | 16-630mm | Certificate: | CE ISO9001 |
| Highlight: | single screw extruder machine,extruder plastic machine |
||
HDPE PP PPR PE Pipe Single Screw Extruder Line With 1 Year Warranty , Fully Automatic
Quick detail
1. HDPE series plastic pipe extrusion line is mainly used in the area of agricultural water supply, architectural water supply, gas supply and transportation, telecommunication cables etc.
2. Pipe Diameter: 16-630mm
3. By different diameter, it may need different type of machine.
4. This line has the advantages of easy operation, high automatic degree, stable and reliable production, well received by customers.
Description:
1. The HDPE PE PPR pipe produciton line's steel structure using advanced laser cutting process to ensure that the production line after assembly accuracy.
2. In order to save customers valuable factory space, we optimized the size of the whole structure, our plastic pipe production line is more compact.
3. More user-friendly design, such as tempered glass cover, allows the operator to easily observe the production status.
4. The electrical system uses the international famous brand, so that the production line to run more reliable and longer life.
5. Using different molds can produce different size pipe.
6.The pipe production line with high automation design, the staff through simple training can produce.
7. We have overseas after-sales service staff,Customers do not have to worry about after-sales service.
Main technical parameters:
| Pipe ranger(mm) | 20-63 | 50-160 | 150-250 | 250-315 | 280-630 |
| Extruder | SJ65/33 | SJ75/33 | SJ90/33 | SJ120/33 | SJ150/33 |
| Capacity(kg/h) | 50-80 | 80-150 | 180-260 | 300-400 | 450-600 |
| Total power(kw) | 75 | 145 | 195 | 220 | 350 |
| Line length | 35 | 38 | 42 | 44 | 56 |
| Control system | PLC | PLC | PLC | PLC | PLC |
If you want more details of our HDPE pipe machine/ HDPE pipe making machine, please let us know!
