Waste Plastic Film Recycling Machine Washing And Granulation Machine ISO9001
Product Details
| Automatic Grade: | Automatic | Certification: | CE, ISO9001 |
|---|---|---|---|
| Warranty: | 12 Months | Key Words: | Recycling Line |
| Capacity: | 150-3000kg/h | Delivery Details:: | 60 Working Days |
| Highlight |
plastic reprocessing machine,plastic waste recycling machine |
||
Product Description
Waste plastic film recycling machine washing and granulation machine ISO9001
PP, PE films/bags recycling washing line description:
This waste plastic recycling and granulation machine is researched, designed and manufactured by our
company, integration of Europe technology, it has features as high efficiency, working stable, large capacity
etc.
Application:
Applicable plastic materials for waste plastic recycling and granulation machine: PP, LDPE, LLDPE, HDPE,
BOPP, etc.
Material shapes: Woven bags, printed LDPE film (rolls, loose, bundled), agriculture film, foamed plastics and
raffia, etc.
Note: depending on material property, various downstream equipment are available.
Working Flow:
Plastic film & bag recycling and washing line (1000kg/h):
Belt conveyor*2→Crusher (with water) *2→ Double screw conveyor*2→Film floating washer→Screw
conveyor→High speed friction machine→Screw conveyor→Horizontal dewatering machine→Drying
system→Transition silo→Drying system→Storage hopper→Control cabinet
Advantages:
1. Final products has good quality. When process PP PE film bags, final products humidity below 5%.
2. The whole line capacity between 150kg/h-2000kg/h (150kg/h, 300kg/h, 500kg/h, 1000kg/h, 2000kg/h)
3. Parts which contact material use SUS304, thickness more than 3mm, ensure long service lift time
4. World famous brand components applied on the production line- SKF bearing, contactor, Omron
temperature, FUJI invertor, PLC control etc.
5. The whole production line with CE certification, ISO9001 certification.
| Plastic PP PE film/bag recycling washing line main components(1000kg): | |
| Name: | Power: |
| Belt conveyor | 2.2kw |
| Crusher | 55kw |
| Screw conveyor | 3kw |
| Belt conveyor | 2.2kw |
| Crusher | 55kw |
| Screw conveyor | 3kw |
| Floating washer | 3kw+3kw+3kw |
| Screw conveyor | 5.5kw |
| High speed frication machine | 45kw |
| Screw conveyor | 5.5kw |
| Horizontal dewatering machine | 110kw +1.5kw |
| Drying system-1 | 48kw+11kw |
| Transition storage hopper | |
| Drying system-2 | 36kw+11kw |
| Storage hopper | 1.5kw+1.5kw |
| Control cabinet | |
SJ series plastic film/bag granulating line/ pelletizing machine:
| SJ series single stage pe pp film granulator machine(with side feeder) | ||||||
| Model | SJ-65 | SJ-80 | SJ-100 | SJ-120 | SJ-150 | SJ-200 |
| Screw Dia. | 65 | 80 | 100 | 120 | 150 | 200 |
| L/D | 28-30 | 28-30 | 28-30 | 28-30 | 28-30 | 28-30 |
| Capacity | 60-80kg/h | 80-100kg/h | 150kg/h | 300kg/h | 400kg/h | 500kg/h |
| SJ series double-stage pe pp film granulator machine(with side feeder) | ||||
| Model | SJ-100/100 | SJ-120/120 | SJ-150/150 | SJ-200/200 |
| Screw Dia. | 100 | 120 | 150 | 200 |
| L/D |
28-30 10-15 |
28-30 10-15 |
28-30 10-15 |
28-30 10-15 |
| Capacity | 120-180kg/h | 220-300kg/h | 300-400kg/h | 500-600kg/h |
