PET Bottle Crushing Machine And Automatic Bottle Washing Machine 300 -2000kg / H
Product Details
| Application: | According To Customer | Automatic Grade: | Automatic |
|---|---|---|---|
| Production Capacity: | 300-2000kg/h | Voltage: | According To Customer |
| Certification: | CE, ISO9001 | Warranty: | 12 Months |
| Raw Material: | Pet Bottle | Key Words: | Recycling Line |
| Highlight |
plastic reprocessing machine,plastic waste recycling machine |
||
Product Description
PET Bottle Crushing Machine And Automatic Bottle Washing Machine 300 -2000kg/H
PET bottle recycling equipment (crushing, washing, and drying):
The whole production equipment is researched, design and manufactured by our company, integration of
Europe technology, it has features as high efficiency, working stable, large capacity etc.
Working flow:
PET bottle recycling equipment (crushing, washing and drying):
Belt conveyor→ Mechanical label remover→ manual separating table→ metal detector → belt conveyor →
Crusher→ Screw conveyor→ floating washer→ screw conveyor → Hot washer → screw conveyor→ high
speed friction machine → screw conveyor → floation washer → screw conveyor → dewatering machine →
drying system → zig zag air classify system → storage hopper → Electric control cabinet
| Waste plastic pet bottle washing recycling machine main components (1000kg/h) | |
| Name: | Power: |
| Belt conveyor | 2.2kw |
| Mechenical label remover | 22kw |
| Manual separating table | 1.5kw |
| Metal detector | 0.4kw |
| Belt conveyor | 2.2kw |
| Crusher | 55kw |
| Screw conveyor | 2.2kw |
| Floating washer | 2.2kw+2.2kw+2.2kw |
| Screw conveyor | 2.2kw |
| Hot washer | 36kw |
| Screw conveyor | 2.2kw |
| High speed frication machine | 22kw |
| Screw conveyor | 2.2kw |
| Floating washer | 2.2kw+2.2kw+2.2kw |
| Screw conveyor | 2.2kw |
| Vertical dewatering machine | 11kw |
| Drying system | 36kw+7kw |
| Zig Zag air classification system | 11kw |
| Storage hopper | |
| Control cabinet | |
Advantages:
- Final products has good quality. When process PET bottle, final products humidity below 1%, impurities 100ppm, PVC label content 100ppm.
- The whole line capacity between 300kg/h-2000kg/hour
- Parts which contact material use SUS304 stainless steel, thickness more than 3mm, ensure long service lift time
- World famous brand components applied on the production line- e.g. SKF bearing, contactor, Omron temperature, ABB inverter, PLC controller, etc.
- The whole production line with CE certification, ISO9001 certification;
Main components:
- Counting feeder
- TSSK series parallel twin screw extruder
- Vacuum system
- Double station hydraulic change net
- Water cooling tank
- Wind dryer
- Cutter
- Control cabinet
